213-0677 Oil Level Switch E320D CTA E345D Oil Pressure Sensor 2130677
| Description | E320D Oil Pressure Sensor, E345D Oil Level Switch, CAT Liquid Level Switch |
| Application | CAT Crawler Excavator |
| Model | CAT E320D, E325D, E330D, E336D, E349D |
| Part No. | 213-0677, 2130677 |
| Quality | China made |
| Weight | 0.2-0.3kgs |
| Packing | Carton box |
| MOQ | 1PC |
| Lead time | About 1-3 working days |
| Payment | TT, Western union, Paypal, Paysend, RMB |
| Warranty | 3 Months |
| Shipping Port | Huangpu Old Port, Shenzhen Yantian,Guangzhou |
Compatible equipment models: 2130677:
EXCAVATOR 311D LRR 312B L 312C 312C L 312D 312D L 312D2 312D2 GC 312D2 L 312E 312E L 313D 313D2 313D2 LGP
314D CR 314D LCR 314E CR 314E LCR 315B L 315C 315D L 316E L 317B LN 318B 318C 318D L 318D2 L 318E L 319C 319D
319D L 319D LN 320B 320C 320C FM 320C L 320D 320D FM 320D FM RR 320D GC 320D L 320D LN 320D LRR 320D RR
320D2 320D2 GC 320D2 L 320E 320E L 320E LN 320E LRR 320E RR 321B 321C 321D LCR 322C 322C FM 323D L 323D LN
323D SA 323D2 L 323E L 324D 324D FM 324D FM LL 324D L 324D LN 324E 324E L 324E LN 325C 325C FM 325D 325D FM
325D FM LL 325D L 325D MH 326D L 328D LCR 329D 329D L 329D LN 329E 329E L 329E LN 330C 330C FM 330C L 330C MH
330D 330D FM 330D L 330D LN 330D MH 336D 336D L 336D LN 336D2 336D2 L 336E 336E H 336E L 336E LH 336E LN 336F L
340D L 340D2 L 345B II 345B II MH 345B L 345C 345C L 345C MH 345D 345D L 345D L VG 349D 349D L 349E 349E L 349E
349F L 365B 365B II 365B L 365C 365C L 365C L MH 374D
FRONT SHOVEL 385C 5090B
GENERATOR SET C18 C32
INDUSTRIAL ENGINE 3126B C15 C18 C6.6 C7.1 C9 C9.3
MOBILE HYD POWER UNIT 323D L 323D LN 324D LN 325C 325D 325D L 329D L 329E 330C 330D 330D L 336D L 336E 336E HVG
345C L 349D L 349E 349E L HVG 365C L 385C 385C L
MOTOR GRADER 120M 2
SHOVEL LOGGER 345C
SITE PREP TRACTOR 2864C 586C
TRACK FELLER BUNCHER 1090 1190 1190T 1290T 1390
Parts for your 345D EXCAVATOR:
| Pos. | Part No | Qty | Parts name | Comments |
| 1. | 3E-7427 | [1] | ADAPTER | |
| 2. | 130-5300 | [1] | CLIP | |
| 3. | 351-0283 | [1] | VALVE AS-SHUTOFF (ENGINE OIL PAN) | |
| | 6V-7238 | [1] | VALVE-SHUTOFF | |
| 3A. | 238-5080 | [1] | SEAL-O-RING | |
| 4. | 9X-6451 | [1] | PLUG-DRAIN (MAGNETIC)(ENGINE OIL PAN) | |
| 5. | 336-7231 | [1] | BELL AS-SUCTION | |
| 5A. | 210-1743 | [1] | ELBOW | |
| 6. | 213-0677 | [1] | SWITCH AS-LIQUID LEVEL (ENGINE OIL) | |
| | 102-8802 | [1] | KIT-RECEPTACLE (2-PIN) | |
| | | | (INCLUDES RECEPTACLE AS & WEDGE) |
| | 9X-3401 | [2] | PIN-CONNECTOR (16-GA TO 18-GA) | |
| | | | -OR- |
| | 126-1767 | [2] | PIN-CONNECTOR (14-GA TO 16-GA) | |
| 7. | 217-3673 | [1] | SEAL-ISOLATION | |
| 8. | 217-3674 | [14] | FASTENER AS | |
| 9. | 229-5331 | [1] | PAN-OIL | |
| 10. | 061-9458 | [2] | SEAL-O-RING | |
| 11. | 238-5082 | [1] | SEAL-O-RING | |
| 12. | 3E-8016 M | [2] | BOLT-SELF-LOCKING (M8X1.25X25-MM) | |
| 13. | 389-3728 | [2] | PLUG AS | |
| | | | (EACH INCLUDES) |
| | 360-3684 | [1] | PLUG | |
| 13A. | 238-5084 | [1] | SEAL-O-RING | |
| 14. | 5P-8211 | [1] | SEAL-O-RING | |
| 15. | 5P-8245 | [2] | WASHER-HARD (13.5X25.5X3-MM THK) | |
| 16. | 6A-5591 M | [2] | BOLT (M12X1.75X25-MM) | |
| 17. | 6N-8863 | [14] | WASHER (10.2X32X2.5-MM THK) | |
| 18. | 6V-4249 M | [13] | BOLT (M10X1.5X50-MM) | |
| 19. | 287-3049 M | [1] | STUD (M10X1.5X50-MM) | |
| 20. | 9M-1974 | [2] | WASHER-HARD (8.8X16X2-MM THK) | |
